PZ120RS

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

PZ120RS

Manufacturer
APEM Inc.
Manufacturer Product Number
PZ120RS
Description
SS KEYBOARD 12 KEY PIEZO BACK MO
Product Status
Active
Detailed Description
Keypad Switch 12 Metal Keys Contacts Matrix Output Non-Illuminated 0.2A @ 24VDC
Datasheet
PZ120RS Datasheet
EDA/CAD Models
PZ120RS Models

Product Attributes

Approval Agency -
Contact Rating @ Voltage 0.2A @ 24VDC
Features -
Illumination Non-Illuminated
Illumination Voltage (Nominal) -
Ingress Protection IP68 - Dust Tight, Waterproof
Key Color Silver
Key Type Metal
Legend Telephone Format
Legend Color Black
Legend Type Fixed
Matrix (Columns x Rows) 3 x 4
Mfr APEM Inc.
Mounting Type Panel Mount, Rear
Number of Keys 12
Operating Temperature -40°C ~ 85°C
Operational Life 10,000,000 Cycles
Output Type Matrix
Package Bag
Panel Cutout Dimensions Rectangular - 81.50mm x 62.50mm
Product Status Active
Series PZ
Termination Style Pin Header
Description Shipping Reviews (2)

Keypad Switch 12 Metal Keys Contacts Matrix Output Non-Illuminated 0.2A @ 24VDC
