MUC-20PFFR-JS8C02

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

MUC-20PFFR-JS8C02

Manufacturer
Amphenol LTW
Manufacturer Product Number
MUC-20PFFR-JS8C02
Description
CONN RCPT USB2.0 MICRO AB SMD RA
Product Status
Active
Detailed Description
USB - micro AB USB 2.0 Receptacle Connector 5 Position Surface Mount, Right Angle
Datasheet
MUC-20PFFR-JS8C02 Datasheet
EDA/CAD Models
MUC-20PFFR-JS8C02 Models

Product Attributes

Base Product Number MUC-20PFFR
Connector Type USB - micro AB
Contact Finish Gold
Current Rating (Amps) 1A, 1.8A
Features Board Lock
Gender Receptacle
Ingress Protection IP68 - Dust Tight, Waterproof
Insulation Color Black
Material Flammability Rating -
Mating Cycles 10000
Mfr Amphenol LTW
Mounting Feature Horizontal
Mounting Type Surface Mount, Right Angle
Number of Contacts 5
Number of Ports 1
Operating Temperature -30°C ~ 85°C
Package Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Product Status Active
Series SWIFT
Shell/Shielding Material Steel, Stainless
Shielding -
Specifications USB 2.0
Termination Solder
Voltage - Rated -
Description Shipping Reviews (2)

USB - micro AB USB 2.0 Receptacle Connector 5 Position Surface Mount, Right Angle
