Integrated Circuit Key Solutions
DC2237A

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

DC2237A

Manufacturer
Analog Devices Inc.
Manufacturer Product Number
DC2237A
Description
DEMO BOARD FOR LTM8064
Product Status
Active
Detailed Description
LTM8064 µModule® DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board
Datasheet
DC2237A Datasheet
EDA/CAD Models
DC2237A Models

Product Attributes

Base Product Number DC2237
Board Type Fully Populated
Current - Output 6A
Frequency - Switching 325kHz
Main Purpose DC/DC, Step Down
Mfr Analog Devices Inc.
Outputs and Type 1, Non-Isolated
Package Box
Product Status Active
Regulator Topology Buck
Series µModule®
Supplied Contents Board(s)
Utilized IC / Part LTM8064
Voltage - Input 7.5V ~ 58V
Voltage - Output 5V
Description Shipping Reviews (2)

LTM8064 µModule® DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board
