Integrated Circuit Key Solutions
DC2270A

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

DC2270A

Manufacturer
Analog Devices Inc.
Manufacturer Product Number
DC2270A
Description
LT3095 DEMO BOARD - DUAL-CHANNEL
Product Status
Active
Detailed Description
LT3095 - DC/DC, Step Up with LDO 2, Non-Isolated Outputs Evaluation Board
Datasheet
DC2270A Datasheet
EDA/CAD Models
DC2270A Models

Product Attributes

Base Product Number DC2270
Board Type Fully Populated
Current - Output 50mA, 50mA
Frequency - Switching 1MHz
Main Purpose DC/DC, Step Up with LDO
Mfr Analog Devices Inc.
Outputs and Type 2, Non-Isolated
Package Box
Product Status Active
Regulator Topology Boost
Series -
Supplied Contents Board(s)
Utilized IC / Part LT3095
Voltage - Input 3V ~ 20V
Voltage - Output 5V, 15V
Description Shipping Reviews (2)

LT3095 - DC/DC, Step Up with LDO 2, Non-Isolated Outputs Evaluation Board
