Integrated Circuit Key Solutions
AE769B11300

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

AE769B11300

Manufacturer
Anatech Electronics Inc.
Manufacturer Product Number
AE769B11300
Description
769 MHZ CAVITY BAND PASS FILTER
Product Status
Active
Detailed Description
769MHz Center Frequency Band Pass RF Filter (Radio Frequency) 27MHz Bandwidth 1.3dB Module, SMA Connectors
Datasheet
AE769B11300 Datasheet
EDA/CAD Models
AE769B11300 Models

Product Attributes

Bandwidth 27MHz
Filter Type Band Pass
Frequency 769MHz Center
Height (Max) 0.886" (22.50mm)
Insertion Loss 1.3dB
Mfr Anatech Electronics Inc.
Mounting Type Chassis Mount
Package Box
Package / Case Module, SMA Connectors
Product Status Active
Ripple -
Series -
Size / Dimension 5.437" L x 3.071" W (138.10mm x 78.00mm)
Description Shipping Reviews (2)

769MHz Center Frequency Band Pass RF Filter (Radio Frequency) 27MHz Bandwidth 1.3dB Module, SMA Connectors
