0ZCF0185FF2C

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

0ZCF0185FF2C

Manufacturer
Bel Fuse Inc.
Manufacturer Product Number
0ZCF0185FF2C
Description
PTC RESET FUSE 33V 1.85A 2920
Product Status
Active
Detailed Description
Polymeric PTC Resettable Fuse 33V 1.85 A Ih Surface Mount 2920 (7351 Metric), Concave
Datasheet
0ZCF0185FF2C Datasheet
EDA/CAD Models
0ZCF0185FF2C Models

Product Attributes

Mfr Bel Fuse Inc.
Series 0ZCF
Package Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Product Status Active
Type Polymeric
Voltage - Max 33V
Current - Max 100 A
Current - Hold (Ih) (Max) 1.85 A
Current - Trip (It) 3.7 A
Time to Trip 2.5 s
Resistance - Initial (Ri) (Min) 40 mOhms
Resistance - Post Trip (R1) (Max) 150 mOhms
Operating Temperature -40°C ~ 85°C
Ratings -
Mounting Type Surface Mount
Package / Case 2920 (7351 Metric), Concave
Size / Dimension 0.290" L x 0.202" W (7.36mm x 5.12mm)
Height - Seated (Max) -
Thickness (Max) 0.035" (0.90mm)
Lead Spacing -
Approval Agency AEC-Q200, cURus, TUV
Description Shipping Reviews (2)

Polymeric PTC Resettable Fuse 33V 1.85 A Ih Surface Mount 2920 (7351 Metric), Concave
