ADS1286PA

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

ADS1286PA

Manufacturer
Burr Brown
Manufacturer Product Number
ADS1286PA
Description
IC ADC 12BIT SAR 8DIP
Product Status
Active
Detailed Description
12 Bit Analog to Digital Converter 1 Input 1 SAR 8-PDIP
Datasheet
ADS1286PA Datasheet
EDA/CAD Models
ADS1286PA Models

Product Attributes

Mfr Burr Brown
Series -
Package Tube
Product Status Obsolete
Number of Bits 12
Sampling Rate (Per Second) 20k
Number of Inputs 1
Input Type Differential
Data Interface SPI
Configuration S/H-ADC
Ratio - S/H:ADC 1:1
Number of A/D Converters 1
Architecture SAR
Reference Type External
Voltage - Supply, Analog 5V
Voltage - Supply, Digital 5V
Features -
Operating Temperature -40°C ~ 85°C
Package / Case 8-DIP (0.300", 7.62mm)
Supplier Device Package 8-PDIP
Mounting Type Through Hole
Description Shipping Reviews (2)

12 Bit Analog to Digital Converter 1 Input 1 SAR 8-PDIP
