ZA9671-BED

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

ZA9671-BED

Manufacturer
Coilcraft
Manufacturer Product Number
ZA9671-BED
Description
TRANSFORMER
Product Status
Active
Detailed Description
Flyback Converters For For DC/DC Converters SMPS Transformer 1500Vrms Isolation 300kHz Surface Mount
Datasheet
ZA9671-BED Datasheet
EDA/CAD Models
ZA9671-BED Models

Product Attributes

Applications Flyback Converters
Chipset Manufacturer Texas Instruments
Footprint 0.520" L x 0.430" W (13.21mm x 10.92mm)
Frequency 300kHz
Height - Seated (Max) 0.394" (10.00mm)
Inductance @ Frequency 9µH @ 300kHz
Intended Chipset LM25184
Mfr Coilcraft
Mounting Type Surface Mount
Operating Temperature -40°C ~ 85°C
Package Strip
Product Status Active
Series -
Size / Dimension -
Style -
Type For DC/DC Converters
Voltage - Auxiliary -
Voltage - Isolation 1500Vrms
Voltage - Primary 4 ~ 42V
Description Shipping Reviews (2)

Flyback Converters For For DC/DC Converters SMPS Transformer 1500Vrms Isolation 300kHz Surface Mount
