A10405RNZQE

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

A10405RNZQE

Manufacturer
C&K
Manufacturer Product Number
A10405RNZQE
Description
SWITCH ROTARY 4POS 2.5A 125V
Product Status
Active
Detailed Description
Rotary Switch 4 Position SP4T 2.5A (AC), 350mA (DC) 125 VAC Panel Mount
Datasheet
A10405RNZQE Datasheet
EDA/CAD Models
A10405RNZQE Models

Product Attributes

Mfr C&K
Series A
Package Tray
Product Status Active
Number of Positions 4
Index Stops Fixed
Number of Decks 1
Number of Poles per Deck 1
Circuit per Deck SP4T
Contact Timing Non-Shorting (BBM)
Current Rating (Amps) 2.5A (AC), 350mA (DC)
Voltage Rating - AC 125 V
Voltage Rating - DC 125 V
Actuator Type Flatted (6.35mm Dia)
Actuator Length 12.70mm
Angle of Throw 30°
Contact Material Silver (Ag)
Contact Finish Silver
Mounting Type Panel Mount
Termination Style Solder Lug
Features Epoxy Sealed Terminals
Depth Behind Panel 20.83mm
Panel Cutout Dimensions Circular - 9.80mm Dia
Base Product Number A10405RN
Description Shipping Reviews (2)

Rotary Switch 4 Position SP4T 2.5A (AC), 350mA (DC) 125 VAC Panel Mount
