AFB0712MB-R00

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

AFB0712MB-R00

Manufacturer
Delta Electronics
Manufacturer Product Number
AFB0712MB-R00
Description
FAN AXIAL 70X15MM 12VDC WIRE
Product Status
Active
Detailed Description
Fan Tubeaxial 12VDC Square - 70mm L x 70mm H Ball 28.2 CFM (0.790m³/min) 3 Wire Leads
Datasheet
AFB0712MB-R00 Datasheet
EDA/CAD Models
AFB0712MB-R00 Models

Product Attributes

Air Flow 28.2 CFM (0.790m³/min)
Approval Agency CE, CSA, UL, VDE
Base Product Number AFB0712
Bearing Type Ball
Current Rating (Amps) 0.140A
Fan Type Tubeaxial
Features Locked Rotor Sensor
Ingress Protection -
Lifetime @ Temp. 70000 Hrs @ 40°C
Material - Blade Plastic
Material - Frame Plastic
Mfr Delta Electronics
Noise 31.0dB(A)
Operating Temperature 14 ~ 158°F (-10 ~ 70°C)
Package Bulk
Power (Watts) 1.68 W
Product Status Active
RPM 3300 RPM
Series AFB
Size / Dimension Square - 70mm L x 70mm H
Static Pressure 0.123 in H2O (30.6 Pa)
Termination 3 Wire Leads
Voltage - Rated 12VDC
Voltage Range 4 ~ 13.8VDC
Weight 0.104 lb (47.17 g)
Width 15.00mm
Description Shipping Reviews (2)

Fan Tubeaxial 12VDC Square - 70mm L x 70mm H Ball 28.2 CFM (0.790m³/min) 3 Wire Leads
