100SP1T5B1M1QEWITHWIRE

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

100SP1T5B1M1QEWITHWIRE

Manufacturer
E-Switch
Manufacturer Product Number
100SP1T5B1M1QEWITHWIRE
Description
INCLUDES WIRE ASSEMBLY
Product Status
Active
Detailed Description
Toggle Switch SPDT Panel Mount
Datasheet
100SP1T5B1M1QEWITHWIRE Datasheet
EDA/CAD Models
100SP1T5B1M1QEWITHWIRE Models

Product Attributes

Mfr E-Switch
Series 100
Package Bulk
Product Status Active
Mounting Type Panel Mount
Circuit SPDT
Switch Function On-On
Current Rating (Amps) 5A (AC/DC)
Voltage Rating - AC 120 V
Voltage Rating - DC 28 V
Actuator Type Standard Round
Actuator Length -
Illumination Non-Illuminated
Illumination Type, Color -
Illumination Voltage (Nominal) -
Termination Style Solder Lug
Panel Cutout Dimensions Circular - 6.35mm Dia
Bushing Thread 1/4-40
Ingress Protection -
Features -
Operating Temperature -30°C ~ 85°C
Actuator Material Brass, Chrome Plated
Electrical Life 40,000 Cycles
Description Shipping Reviews (2)

Toggle Switch SPDT Panel Mount
