H2061-01

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

H2061-01

Manufacturer
Harwin Inc.
Manufacturer Product Number
H2061-01
Description
TERM TURRET SINGLE L=3.18MM TIN
Product Status
Active
Detailed Description
Terminal Turret Connector Single End 0.125" (3.18mm) Tin
Datasheet
H2061-01 Datasheet
EDA/CAD Models
H2061-01 Models

Product Attributes

Mfr Harwin Inc.
Series -
Package Bulk
Product Status Active
Terminal Type Single End
Number of Turrets Single
Length - Above Board 0.125" (3.18mm)
Length - Below Flange 0.094" ~ 0.099" (2.39mm ~ 2.51mm)
Length - Overall 0.219" (5.56mm)
Mounting Type Through Hole
Termination Swage
Flange Diameter 0.156" ~ 0.161" (3.96mm ~ 4.09mm)
Diameter - Turret Head 0.089" ~ 0.094" (2.26mm ~ 2.39mm)
Staking Side OD 0.059" ~ 0.063" (1.50mm ~ 1.59mm)
Staking Side ID -
Mounting Hole Diameter 0.063" ~ 0.066" (1.60mm ~ 1.68mm)
Board Thickness 0.063" (1.60mm)
Contact Material Brass Alloy
Contact Finish Tin
Contact Finish Thickness -
Insulation Non-Insulated
Material - Insulation -
Insulation Color -
Base Product Number H2061
Description Shipping Reviews (2)

Terminal Turret Connector Single End 0.125" (3.18mm) Tin
