Product Attributes

Mfr Mill-Max Manufacturing Corp.
Series 2301
Package Bulk
Product Status Active
Terminal Type Single End
Number of Turrets Single
Length - Above Board 0.093" (2.36mm)
Length - Below Flange 0.053" (1.35mm)
Length - Overall 0.146" (3.71mm)
Mounting Type Through Hole
Termination Swage
Flange Diameter 0.094" (2.39mm)
Diameter - Turret Head 0.063" (1.60mm)
Staking Side OD 0.062" (1.57mm)
Staking Side ID 0.046" (1.17mm)
Mounting Hole Diameter 0.067" (1.70mm)
Board Thickness 0.031" (0.79mm)
Contact Material Brass Alloy
Contact Finish Tin
Contact Finish Thickness 200.0µin (5.08µm)
Insulation Non-Insulated
Material - Insulation -
Insulation Color -
Base Product Number 2301-1
Description Shipping Reviews (2)

Terminal Turret Connector Single End 0.093" (2.36mm) Tin
