Product Attributes

Mfr Mill-Max Manufacturing Corp.
Series 2320
Package Bulk
Product Status Active
Terminal Type PC Pin
Terminal Style Single End, Slotted
Pin Size - Above Flange 0.094" (2.39mm) Dia
Pin Size - Below Flange -
Length - Above Flange 0.281" (7.14mm)
Length - Below Flange 0.084" (2.13mm)
Length - Overall 0.365" (9.27mm)
Flange Diameter 0.094" (2.39mm)
Mounting Hole Diameter 0.064" (1.63mm)
Mounting Type Through Hole
Termination Swage
Insulation Non-Insulated
Board Thickness 0.062" (1.57mm)
Contact Material Brass Alloy
Contact Finish Tin
Contact Finish Thickness 200.0µin (5.08µm)
Material - Insulation -
Insulation Color -
Base Product Number 2320-2
Description Shipping Reviews (2)

PC Pin Terminal Connector Through Hole Tin 0.094" (2.39mm) Dia
