0395437115

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

0395437115

Manufacturer
Molex
Manufacturer Product Number
0395437115
Description
TERM BLK 15POS TOP ENTRY 5MM PCB
Product Status
Active
Detailed Description
15 Position Wire to Board Terminal Block Vertical with Board 0.197" (5.00mm) Through Hole
Datasheet
0395437115 Datasheet
EDA/CAD Models
0395437115 Models

Product Attributes

Base Product Number 039543
Clamp Material - Plating Brass
Color Black
Contact Material - Plating Brass - Tin Plated
Current 10 A
Features Interlocking (Side), Positions Stamped
Housing Material Polyamide (PA66), Nylon 6/6
Mating Orientation Vertical with Board
Mfr Molex
Mounting Type Through Hole
Number of Levels 1
Operating Temperature -40°C ~ 105°C
Package Bulk
Pitch 0.197" (5.00mm)
Positions Per Level 15
Product Status Active
Screw Material - Plating Steel
Screw Thread -
Series Eurostyle ESE 39543
Torque - Screw 0.4 Nm (3.5 Lb-In)
Voltage 300 V
Wire Gauge 16-24 AWG
Wire Termination Screw - Rising Cage Clamp
Description Shipping Reviews (2)

15 Position Wire to Board Terminal Block Vertical with Board 0.197" (5.00mm) Through Hole
