Integrated Circuit Key Solutions
0765609707

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

0765609707

Manufacturer
Molex
Manufacturer Product Number
0765609707
Description
CONN HDR IMPACT 252POS EDGE MNT
Product Status
Active
Detailed Description
252 Connector Header, Male Pins Board Edge, Through Hole, Right Angle Black Impact, Guide Right
Datasheet
0765609707 Datasheet
EDA/CAD Models
0765609707 Models

Product Attributes

Mfr Molex
Series Impact 76560
Package Tray
Product Status Active
Connector Usage -
Connector Type Header, Male Pins
Connector Style Impact, Guide Right
Number of Positions 252
Number of Positions Loaded All
Pitch 0.053" (1.35mm)
Number of Rows 18
Number of Columns 14
Mounting Type Board Edge, Through Hole, Right Angle
Termination Press-Fit
Contact Layout, Typical 84 Differential Pairs
Features -
Contact Finish Gold
Contact Finish Thickness 30.0µin (0.76µm)
Color Black
Current Rating (Amps) -
Material Flammability Rating UL94 V-0
Operating Temperature -55°C ~ 85°C
Voltage Rating 30V
Base Product Number 076560
Description Shipping Reviews (2)

252 Connector Header, Male Pins Board Edge, Through Hole, Right Angle Black Impact, Guide Right
