FMBN16BD

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

FMBN16BD

Manufacturer
NKK Switches
Manufacturer Product Number
FMBN16BD
Description
SWITCH KEYPAD 16 KEY 0.02A 24V
Product Status
Active
Detailed Description
Keypad Switch 16 Polyester Overlay Keys Membrane (Snap Dome) Contacts Matrix Output Non-Illuminated 0.02A @ 24VDC
Datasheet
FMBN16BD Datasheet
EDA/CAD Models
FMBN16BD Models

Product Attributes

Mfr NKK Switches
Series FM
Package Box
Product Status Active
Switch Type Membrane (Snap Dome)
Number of Keys 16
Matrix (Columns x Rows) 4 x 4
Illumination Non-Illuminated
Legend Type Interchangeable
Key Type Polyester Overlay
Output Type Matrix
Legend Customizable (Included)
Legend Color -
Key Color Transparent
Mounting Type Panel Mount, Front
Termination Style Cable with Connector
Panel Cutout Dimensions -
Operating Temperature -15°C ~ 55°C
Ingress Protection -
Illumination Voltage (Nominal) -
Contact Rating @ Voltage 0.02A @ 24VDC
Features -
Operational Life 1,000,000 Cycles
Approval Agency -
Base Product Number FMBN16
Description Shipping Reviews (2)

Keypad Switch 16 Polyester Overlay Keys Membrane (Snap Dome) Contacts Matrix Output Non-Illuminated 0.02A @ 24VDC
