FMBP12BF

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

FMBP12BF

Manufacturer
NKK Switches
Manufacturer Product Number
FMBP12BF
Description
SWITCH KEYPAD 12 KEY 0.02A 24V
Product Status
Active
Detailed Description
Keypad Switch 12 Polyester Overlay Keys Membrane (Snap Dome) Contacts Matrix Output Illuminated - Amber 0.02A @ 24VDC
Datasheet
FMBP12BF Datasheet
EDA/CAD Models
FMBP12BF Models

Product Attributes

Mfr NKK Switches
Series FM
Package Box
Product Status Active
Switch Type Membrane (Snap Dome)
Number of Keys 12
Matrix (Columns x Rows) 3 x 4
Illumination Illuminated - Amber
Legend Type Fixed
Key Type Polyester Overlay
Output Type Matrix
Legend Telephone Format
Legend Color Gray
Key Color White
Mounting Type Panel Mount, Front
Termination Style Cable with Connector
Panel Cutout Dimensions -
Operating Temperature -15°C ~ 50°C
Ingress Protection -
Illumination Voltage (Nominal) 2.1 VDC
Contact Rating @ Voltage 0.02A @ 24VDC
Features -
Operational Life 1,000,000 Cycles
Approval Agency -
Base Product Number FMBP12
Description Shipping Reviews (2)

Keypad Switch 12 Polyester Overlay Keys Membrane (Snap Dome) Contacts Matrix Output Illuminated - Amber 0.02A @ 24VDC
