AS04008MR-21-R

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

AS04008MR-21-R

Manufacturer
PUI Audio, Inc.
Manufacturer Product Number
AS04008MR-21-R
Description
SPEAKER 1W 8 OHM 89 DB 630 HZ MY
Product Status
Active
Detailed Description
8 Ohms General Purpose Speaker 1 W 630 Hz ~ 6 kHz Top Round
Datasheet
AS04008MR-21-R Datasheet
EDA/CAD Models
AS04008MR-21-R Models

Product Attributes

Distortion Rating -
Efficiency - dBA 89.00
Efficiency - Testing 1W/1M
Efficiency - Type Sound Pressure Level (SPL)
Frequency - Self Resonant 630Hz
Frequency Range 630 Hz ~ 6 kHz
Height - Seated (Max) 0.197" (5.00mm)
Impedance 8 Ohms
Ingress Protection -
Material - Cone Polyester, Polyethylene Terephthalate (PET)
Material - Magnet Nd-Fe-B
Mfr PUI Audio, Inc.
Operating Temperature -20°C ~ 60°C
Package Box
Port Location Top
Power - Max 1.5 W
Power - Rated 1 W
Product Status Active
Ratings -
Series AS
Shape Round
Size / Dimension 1.575" Dia (40.00mm)
Technology Magnetic
Termination Solder Pads
Type General Purpose
Description Shipping Reviews (2)

8 Ohms General Purpose Speaker 1 W 630 Hz ~ 6 kHz Top Round
