ESE-15800

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

ESE-15800

Manufacturer
Panasonic Electronic Components
Manufacturer Product Number
ESE-15800
Description
SWITCH SLIDE SPDT 1MA 10V
Product Status
Active
Detailed Description
Slide Switch SPDT Surface Mount, Right Angle
Datasheet
ESE-15800 Datasheet
EDA/CAD Models
ESE-15800 Models

Product Attributes

Mfr Panasonic Electronic Components
Series ESE
Package Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Product Status Obsolete
Circuit SPDT
Contact Timing Not Specified
Switch Function Mom-Off-Mom
Current Rating (Amps) 1mA (DC)
Voltage Rating - DC 10 V
Actuator Type Standard
Actuator Length 0.90mm
Contact Material Copper Alloy
Contact Finish Silver
Mounting Type Surface Mount, Right Angle
Termination Style Gull Wing
Features -
Operating Temperature -
Actuator Material Polyamide (PA), Nylon
Switch Travel 1.50mm
Mechanical Life -
Electrical Life -
Operating Force 127gf
Base Product Number ESE-15
Description Shipping Reviews (2)

Slide Switch SPDT Surface Mount, Right Angle
