SG-D1-2C11

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

SG-D1-2C11

Manufacturer
Panasonic Industrial Automation Sales
Manufacturer Product Number
SG-D1-2C11
Description
SWITCH KEYLCK 2POS DPST 10A 110V
Product Status
Active
Detailed Description
Keylock Switch 2 Position DPST-NO/NC 10A (AC), 8A (DC) 110 VAC 24 VDC Panel Mount
Datasheet
SG-D1-2C11 Datasheet
EDA/CAD Models
SG-D1-2C11 Models

Product Attributes

Mfr Panasonic Industrial Automation Sales
Series SG-D1
Package Bulk
Product Status Obsolete
Circuit DPST-NO/NC
Number of Positions 2
Switch Function On-Off, Off-On
Contact Timing Not Specified
Current Rating (Amps) 10A (AC), 8A (DC)
Voltage Rating - AC 110 V
Voltage Rating - DC 24 V
Actuator Type Flat Key
Key Removable Positions 2 only
Angle of Throw 90°
Contact Material -
Contact Finish -
Mounting Type Panel Mount
Termination Style Screw Terminal
Panel Cutout Dimensions Circular - 22.30mm Dia
Features IP65
Operating Temperature -25°C ~ 60°C
Depth Behind Flange 49.40mm
Mechanical Life 100,000 Cycles
Electrical Life 100,000 Cycles
Base Product Number SG-D1-2
Description Shipping Reviews (2)

Keylock Switch 2 Position DPST-NO/NC 10A (AC), 8A (DC) 110 VAC 24 VDC Panel Mount
