0906-1

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

0906-1

Manufacturer
Preci-Dip
Manufacturer Product Number
0906-1
Description
CONTACT SPRING LOADED T/H GOLD W
Product Status
Active
Detailed Description
Contact Spring Through Hole
Datasheet
0906-1 Datasheet
EDA/CAD Models
0906-1 Models

Product Attributes

Contact Finish Gold
Contact Finish Thickness 20.0µin (0.51µm)
Contact Material Brass
Contact Type Sleeve & Plunger (Pogo Pins)
Current Rating (Amps) 2A
Features -
Material Flammability Rating -
Mating Cycles 100000
Maximum Working Height 0.177" (4.50mm)
Mfr Preci-Dip
Minimum Working Height 0.122" (3.10mm)
Mounting Type Through Hole
Operating Force - Initial 25.49gf
Operating Force - Mid Compression 91.77gf
Operating Temperature -55°C ~ 125°C
Package Bulk
Pad Layout Dimension Circular - 0.072" (1.83mm)
Plunger Size 0.042" (1.07mm) Dia
Product Status Active
Recommended Working Height 0.125" (3.18mm)
Series 0906
Description Shipping Reviews (2)

Contact Spring Through Hole
