Integrated Circuit Key Solutions
1.10118.6120000

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

1.10118.6120000

Manufacturer
RAFI USA
Manufacturer Product Number
1.10118.6120000
Description
KEYLOCK SWITCH 90
Product Status
Active
Detailed Description
Keylock Switch 2 Position SPST 100mA (AC/DC) 35 VAC 35 VDC Panel Mount
Datasheet
1.10118.6120000 Datasheet
EDA/CAD Models
1.10118.6120000 Models

Product Attributes

Actuator Type Flat Key
Angle of Throw 90°
Base Product Number 1.10118
Circuit SPST
Contact Finish Gold Alloy
Contact Material -
Contact Timing Not Specified
Current Rating (Amps) 100mA (AC/DC)
Depth Behind Flange 39.50mm
Electrical Life 50,000 Cycles
Features -
Key Removable Positions All
Mechanical Life 50,000 Cycles
Mfr RAFI USA
Mounting Type Panel Mount
Number of Positions 2
Operating Temperature -25°C ~ 70°C
Package Bulk
Panel Cutout Dimensions Circular - 16.20mm Dia
Product Status Obsolete
Series -
Switch Function Off-On
Termination Style Solder Lug
Voltage Rating - AC 35 V
Voltage Rating - DC 35 V
Description Shipping Reviews (2)

Keylock Switch 2 Position SPST 100mA (AC/DC) 35 VAC 35 VDC Panel Mount
