Integrated Circuit Key Solutions
R577443002

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

R577443002

Manufacturer
Radiall USA, Inc.
Manufacturer Product Number
R577443002
Description
DPDT RAMSES SMA 18GHZ LATCHING I
Product Status
Active
Detailed Description
RF Switch IC General Purpose DPDT 50Ohm
Datasheet
R577443002 Datasheet
EDA/CAD Models
R577443002 Models

Product Attributes

Circuit DPDT
Features -
Frequency Range 0Hz ~ 18GHz
IIP3 -
Impedance 50Ohm
Insertion Loss 0.5dB (max)
Isolation 60dB (min)
Mfr Radiall USA, Inc.
Operating Temperature -40°C ~ 85°C
P1dB -
Package Bulk
Package / Case Module
Product Status Active
RF Type General Purpose
Series -
Supplier Device Package -
Test Frequency 18GHz
Topology -
Voltage - Supply 24V ~ 30V
Description Shipping Reviews (2)

RF Switch IC General Purpose DPDT 50Ohm
