BA6222

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

BA6222

Manufacturer
Rohm Semiconductor
Manufacturer Product Number
BA6222
Description
IC MOTOR DRIVER 8V-18V 10HSIP
Product Status
Active
Detailed Description
Motor Driver Bipolar On/Off 10-HSIP
Datasheet
BA6222 Datasheet
EDA/CAD Models
BA6222 Models

Product Attributes

Applications General Purpose
Base Product Number BA622
Current - Output 2A
Function Driver - Fully Integrated, Control and Power Stage
Interface On/Off
Mfr Rohm Semiconductor
Motor Type - AC, DC Brushed DC
Motor Type - Stepper -
Mounting Type Through Hole
Operating Temperature -25°C ~ 125°C (TJ)
Output Configuration Half Bridge (2)
Package Tube
Package / Case 10-SIP Exposed Tab
Product Status Obsolete
Series -
Step Resolution -
Supplier Device Package 10-HSIP
Technology Bipolar
Voltage - Load 8V ~ 18V
Voltage - Supply 8V ~ 18V
Description Shipping Reviews (2)

Motor Driver Bipolar On/Off 10-HSIP
