SDCW2012-2-900TF

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

SDCW2012-2-900TF

Manufacturer
Shenzhen Sunlord Electronics Co., Ltd.
Manufacturer Product Number
SDCW2012-2-900TF
Description
CMC 330MA 2LN 90 OHM SMD
Product Status
Active
Detailed Description
2 Line Common Mode Choke Surface Mount 90 Ohms @ 100 MHz 330mA DCR 350mOhm
Datasheet
SDCW2012-2-900TF Datasheet
EDA/CAD Models
SDCW2012-2-900TF Models

Product Attributes

Approval Agency -
Current Rating (Max) 330mA
DC Resistance (DCR) (Max) 350mOhm
Features -
Filter Type Signal Line
Height (Max) 0.055" (1.40mm)
Impedance @ Frequency 90 Ohms @ 100 MHz
Mfr Shenzhen Sunlord Electronics Co., Ltd.
Mounting Type Surface Mount
Number of Lines 2
Operating Temperature -40°C ~ 85°C
Package Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Package / Case 0805 (2012 Metric), 4 PC Pad
Product Status Active
Ratings -
Series SDCW
Size / Dimension 0.079" L x 0.047" W (2.00mm x 1.20mm)
Voltage Rating - AC -
Voltage Rating - DC 50V
Description Shipping Reviews (2)

2 Line Common Mode Choke Surface Mount 90 Ohms @ 100 MHz 330mA DCR 350mOhm
