Integrated Circuit Key Solutions
SM100B

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

SM100B

Manufacturer
Simplex Motion AB
Manufacturer Product Number
SM100B
Description
Integrated Servomotor 100W, 12-2
Product Status
Active
Detailed Description
Brushless (BLDC) DC Motor Servomotor 6000 RPM 100W Incremental 12 ~ 24VDC
Datasheet
SM100B Datasheet
EDA/CAD Models
SM100B Models

Product Attributes

Diameter - Shaft 0.315" (8.00mm)
Encoder Type Incremental
Features Integrated Controller
Function Servomotor
Gear Reduction Ratio -
Length - Shaft and Bearing 0.709" (18.00mm)
Mfr Simplex Motion AB
Motor Type Brushless (BLDC)
Mounting Hole Spacing 1.969" (50.00mm)
Operating Temperature -20°C ~ 85°C
Package Retail Package
Power - Rated 100W
Product Status Active
RPM 6000 RPM
Series -
Size / Dimension Rectangular - 2.913" x 2.520" (74.00mm x 64.00mm)
Termination Style Connector
Torque - Max Momentary (oz-in / mNm) 280 / 2000
Torque - Rated (oz-in / mNm) 45 / 320
Type DC Motor
Voltage - Rated 12 ~ 24VDC
Description Shipping Reviews (2)

Brushless (BLDC) DC Motor Servomotor 6000 RPM 100W Incremental 12 ~ 24VDC
