3-100159-0

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

3-100159-0

Manufacturer
TE Connectivity AMP Connectors
Manufacturer Product Number
3-100159-0
Description
CONN HEADER 55POS 2MM PRESS-FIT
Product Status
Active
Detailed Description
55 Position Header, Male Pins Connector 0.079" (2.00mm) Through Hole
Datasheet
3-100159-0 Datasheet
EDA/CAD Models
3-100159-0 Models

Product Attributes

Base Product Number 100159
Connector Style C 11
Connector Type Header, Male Pins
Connector Usage Backplane
Contact Finish Gold
Contact Finish Thickness 30.0µin (0.76µm)
Current Rating (Amps) 1.5 A
Features Board Guide
Mfr TE Connectivity AMP Connectors
Mounting Type Through Hole
Number of Positions 55
Number of Positions Loaded All
Number of Rows 5
Operating Temperature -55°C ~ 125°C
Package Bulk
Pitch 0.079" (2.00mm)
Product Status Active
Series Z-PACK
Termination Press-Fit
Voltage Rating 500Vrms
Description Shipping Reviews (2)

55 Position Header, Male Pins Connector 0.079" (2.00mm) Through Hole
