1617132-8

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

1617132-8

Manufacturer
TE Connectivity Aerospace, Defense and Marine
Manufacturer Product Number
1617132-8
Description
JMSWD-5XP = M39016/16-017P
Product Status
Active
Detailed Description
General Purpose Relay DPDT (2 Form C) Through Hole
Datasheet
1617132-8 Datasheet
EDA/CAD Models
1617132-8 Models

Product Attributes

Coil Current 50 mA
Coil Insulation -
Coil Resistance 100 Ohms
Coil Type Non Latching
Coil Voltage 5VDC
Contact Form DPDT (2 Form C)
Contact Material Silver Palladium (AgPd), Gold (Au)
Contact Rating (Current) 1 A
Features Diode
Mfr TE Connectivity Aerospace, Defense and Marine
Mounting Type Through Hole
Must Operate Voltage 2.6 VDC
Must Release Voltage 0.23 VDC
Operate Time 4 ms
Operating Temperature -65°C ~ 125°C
Package Bulk
Product Status Active
Relay Type General Purpose
Release Time 7.5 ms
Seal Rating Sealed - Hermetically
Series MSWD
Switching Voltage 28VDC - Nom
Termination Style PC Pin
Description Shipping Reviews (2)

General Purpose Relay DPDT (2 Form C) Through Hole
