053009

Manufacturer
TE Connectivity Erni
Manufacturer Product Number
053009
Description
2MM HM C 77POS M 3.7MM
Product Status
Active
Detailed Description
77 (55 + 22 Ground) Position Header, Male Pins Connector 0.079" (2.00mm) Through Hole
Datasheet
053009 Datasheet
EDA/CAD Models
053009 Models

Product Attributes

Mfr TE Connectivity Erni
Series ERMET
Package Tray
Product Status Obsolete
Connector Type Header, Male Pins
Connector Style C 11
Number of Positions 77 (55 + 22 Ground)
Number of Positions Loaded All
Pitch 0.079" (2.00mm)
Number of Rows 5 + 2
Mounting Type Through Hole
Termination Press-Fit
Connector Usage -
Contact Finish -
Contact Finish Thickness -
Voltage Rating -
Operating Temperature -
Features Board Guide, Shielded
Base Product Number -
Description Shipping Reviews (2)

77 (55 + 22 Ground) Position Header, Male Pins Connector 0.079" (2.00mm) Through Hole
