Integrated Circuit Key Solutions
TS63420K

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

TS63420K

Manufacturer
Tagore Technology
Manufacturer Product Number
TS63420K
Description
IC RF SWITCH SP4T 1GHZ 16QFN
Product Status
Active
Detailed Description
RF Switch IC Cellular SP4T 50Ohm 16-QFN (3x3)
Datasheet
TS63420K Datasheet
EDA/CAD Models
TS63420K Models

Product Attributes

Base Product Number TS63420
Circuit SP4T
Features -
Frequency Range 1MHz ~ 1GHz
IIP3 71dBm
Impedance 50Ohm
Insertion Loss 0.40dB
Isolation 25dB
Mfr Tagore Technology
Mounting Type Surface Mount
Operating Temperature -40°C ~ 85°C
P1dB 42dBm
Package Strip
Package / Case 16-VFQFN Exposed Pad
Product Status Active
RF Type Cellular
Series Symmetric
Supplier Device Package 16-QFN (3x3)
Test Frequency 500MHz
Topology Reflective
Voltage - Supply 2.6V ~ 5.5V
Description Shipping Reviews (2)

RF Switch IC Cellular SP4T 50Ohm 16-QFN (3x3)
