CSD95492QVM

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

CSD95492QVM

Manufacturer
Texas Instruments
Manufacturer Product Number
CSD95492QVM
Description
POWERSTAGE
Product Status
Active
Detailed Description
Half Bridge (3) Driver Synchronous Buck Converters Power MOSFET 18-VSON (5x4)
Datasheet
CSD95492QVM Datasheet
EDA/CAD Models
CSD95492QVM Models

Product Attributes

Mfr Texas Instruments
Series NexFET™
Package Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Product Status Active
Output Configuration Half Bridge (3)
Applications Synchronous Buck Converters
Interface PWM
Load Type Inductive, Capacitive
Technology Power MOSFET
Rds On (Typ) -
Current - Output / Channel 20A
Current - Peak Output 30A
Voltage - Supply 4.5V ~ 5.5V
Voltage - Load 4.5V ~ 16V
Operating Temperature -40°C ~ 125°C (TJ)
Features Bootstrap Circuit
Fault Protection Shoot-Through
Mounting Type Surface Mount
Package / Case 18-PowerTFDFN
Supplier Device Package 18-VSON (5x4)
Base Product Number CSD95492
Description Shipping Reviews (2)

Half Bridge (3) Driver Synchronous Buck Converters Power MOSFET 18-VSON (5x4)
