RB1-125BAG1A

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

RB1-125BAG1A

Manufacturer
WIZnet
Manufacturer Product Number
RB1-125BAG1A
Description
CONN JACK 1PORT 100 BASE-T PCB
Product Status
Active
Detailed Description
1 Port RJ45Through Hole 10/100 Base-T, AutoMDIX
Datasheet
RB1-125BAG1A Datasheet
EDA/CAD Models
RB1-125BAG1A Models

Product Attributes

Applications 10/100 Base-T, AutoMDIX
Base Product Number RB1-125
Connector Type RJ45
Contact Finish Gold
Contact Finish Thickness Flash
Contact Material Phosphor Bronze
Features Board Lock
Height Above Board 0.525" (13.33mm)
Housing Material Thermoplastic
LED Color Green - Yellow
Mfr WIZnet
Mounting Type Through Hole
Number of Cores per Jack 4
Number of Ports 1
Number of Rows 1
Operating Temperature 0°C ~ 70°C
Orientation 90° Angle (Right)
Package Tray
Product Status Active
Series -
Shield Material Stainless Steel
Shielding Shielded, EMI Finger
Tab Direction Down
Termination Solder
Description Shipping Reviews (2)

1 Port RJ45Through Hole 10/100 Base-T, AutoMDIX
