12401808E412A

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

12401808E412A

Manufacturer
Amphenol ICC (Commercial Products)
Manufacturer Product Number
12401808E412A
Description
USB3.2 GEN2, TYPE C, TOP MOUNT,
Product Status
Active
Detailed Description
USB-C (USB TYPE-C) Receptacle Connector 24 Position Surface Mount, Right Angle; Through Hole
Datasheet
12401808E412A Datasheet
EDA/CAD Models
12401808E412A Models

Product Attributes

Mfr Amphenol ICC (Commercial Products)
Series -
Package Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Product Status Active
Connector Type USB-C (USB TYPE-C)
Number of Contacts 24
Gender Receptacle
Specifications -
Mounting Type Surface Mount, Right Angle; Through Hole
Mounting Feature Horizontal
Termination Solder
Features -
Ingress Protection -
Operating Temperature -
Number of Ports 1
Current Rating (Amps) -
Voltage - Rated -
Mating Cycles -
Shielding Shielded
Contact Finish Gold
Shell/Shielding Material Steel, Stainless
Material Flammability Rating UL94 V-0
Insulation Color Black
Description Shipping Reviews (2)

USB-C (USB TYPE-C) Receptacle Connector 24 Position Surface Mount, Right Angle; Through Hole
