H9030-01

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

H9030-01

Manufacturer
Harwin Inc.
Manufacturer Product Number
H9030-01
Description
TERM TURRET HOLLOW L=8.08-8.58MM
Product Status
Active
Detailed Description
Terminal Turret Connector Single End, Hollow 0.318" ~ 0.338" (8.08mm ~ 8.58mm) Tin
Datasheet
H9030-01 Datasheet
EDA/CAD Models
H9030-01 Models

Product Attributes

Mfr Harwin Inc.
Series -
Package Bulk
Product Status Active
Terminal Type Single End, Hollow
Number of Turrets Triple
Length - Above Board 0.318" ~ 0.338" (8.08mm ~ 8.58mm)
Length - Below Flange 0.100" ~ 0.110" (2.54mm ~ 2.79mm)
Length - Overall 0.418" (10.62mm)
Mounting Type Through Hole
Termination Swage
Flange Diameter 0.187" (4.75mm)
Diameter - Turret Head 0.135" ~ 0.145" (3.43mm ~ 3.68mm)
Staking Side OD 0.107" ~ 0.117" (2.73mm ~ 2.98mm)
Staking Side ID 0.065" ~ 0.075" (1.65mm ~ 1.91mm)
Mounting Hole Diameter 0.115" ~ 0.119" (2.93mm ~ 3.01mm)
Board Thickness 0.063" (1.60mm)
Contact Material Brass Alloy
Contact Finish Tin
Contact Finish Thickness -
Insulation Non-Insulated
Material - Insulation -
Insulation Color -
Base Product Number H9030
Description Shipping Reviews (2)

Terminal Turret Connector Single End, Hollow 0.318" ~ 0.338" (8.08mm ~ 8.58mm) Tin
