BAV70DW-AU_R1_000A1

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

BAV70DW-AU_R1_000A1

Manufacturer
Panjit International Inc.
Manufacturer Product Number
BAV70DW-AU_R1_000A1
Description
SOT-363, SWITCHING
Product Status
Active
Detailed Description
Diode Array 2 Pair Common Cathode Standard 100 V 150mA Surface Mount 6-TSSOP, SC-88, SOT-363
Datasheet
BAV70DW-AU_R1_000A1 Datasheet
EDA/CAD Models
BAV70DW-AU_R1_000A1 Models

Product Attributes

Mfr Panjit International Inc.
Series Automotive, AEC-Q101
Package Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Product Status Active
Diode Configuration 2 Pair Common Cathode
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) (per Diode) 150mA
Voltage - Forward (Vf) (Max) @ If 1.25 V @ 150 mA
Speed Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr) 4 ns
Current - Reverse Leakage @ Vr 2.5 µA @ 100 V
Operating Temperature - Junction -55°C ~ 150°C
Mounting Type Surface Mount
Package / Case 6-TSSOP, SC-88, SOT-363
Supplier Device Package SOT-363
Description Shipping Reviews (2)

Diode Array 2 Pair Common Cathode Standard 100 V 150mA Surface Mount 6-TSSOP, SC-88, SOT-363
