ACPL-H342-000E

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

ACPL-H342-000E

Manufacturer
Broadcom Limited
Manufacturer Product Number
ACPL-H342-000E
Description
OPTOISO 3.75KV 1CH GATE DRVR 8SO
Product Status
Active
Detailed Description
2.5A Gate Driver Optical Coupling 3750Vrms 1 Channel 8-SO Stretched
Datasheet
ACPL-H342-000E Datasheet
EDA/CAD Models
ACPL-H342-000E Models

Product Attributes

Mfr Broadcom Limited
Series -
Package Tube
Product Status Active
Technology Optical Coupling
Number of Channels 1
Voltage - Isolation 3750Vrms
Common Mode Transient Immunity (Min) 25kV/µs
Propagation Delay tpLH / tpHL (Max) 350ns, 250ns
Pulse Width Distortion (Max) -
Rise / Fall Time (Typ) 22ns, 18ns
Current - Output High, Low 2A, 2A
Current - Peak Output 2.5A
Voltage - Forward (Vf) (Typ) 1.55V
Current - DC Forward (If) (Max) 25 mA
Voltage - Output Supply 15V ~ 30V
Operating Temperature -40°C ~ 105°C
Mounting Type Surface Mount
Package / Case 8-SOIC (0.268", 6.81mm Width)
Supplier Device Package 8-SO Stretched
Approval Agency CSA, UR
Base Product Number ACPL-H342
